3500KG Weight Copper Wire/Cable Granulating Machine 99.99% Recycling Ratio Guaranteed

High profit!!! 99.99% high recycling ratio of copper wire/cable granulating machine

Our main purpose:

We Provide complete service equipment installation, testing ,maintenance and staff Training,we can provide you the technical services for life and provide the best service to you . Help our clients gain profit in quicklly. We will provide the most environment friendly and safe products with high quality at most favorable price for the customer with perfect after service.

Introduction of copper wire/cable granulating machine:

My company developed into a complete production line of Model 600 copper recycling machine (mainly recycling car line,communication cable,miscellaneous line),the device structure is novel,unique,compact,small power consumption,stable performance,one feeding,it can complete with its single machine.

After the separation equipment to complete the cable broken in the process of copper

and plastic separation and recovery.Equipment production pattern,good dust removal

equipment,production is controlled by a control box.Successful development of the

machine solved the pollution caused by burning take copper.Not only improve the quality

of the recovery of copper effect,and has the advantages of recycled plastics.

Working Principle of copper wire/cable granulating machine:

♥.1)Materials are crushed in the crusher to have plastic skin and copper granules;

♥.2)The crushed materials (mixture of copper and plastic) are conveyed to the separator by the conveyor, during which procedure the plastic granules (including fiber, rope, or tapes, etc. mixed in the wires) are cleaned by the dust cleaner.

♥.3)The separator is consist of separating board, eccentric device, adjustable amplitude device,and speed adjustable motor, etc. It is used to separate plastic and copper.

♥.4)All units are installed on the underbed to form a whole structure, easy for transportation. The machine is adjusted ready for production before shipment,and customer only need to connect it to the power supply.

After the separation equipment to complete the cable broken in the process of copper and plastic separation and recovery. Equipment production pattern,good dust removal

equipment,production is controlled by a control box. Successful development of the

machine solved the pollution caused by burning take copper. Not only improve the quality

of the recovery of copper effect,and has the advantages of recycled plastics.

When directly put into the machine, used cable is cut into granules first, during this process, copper and plastic is separated but mixed together, then the granules are sent to vibration device for separation,  through wind blow and vibration, the copper and plastic are separated, then pure copper comes out from one side and pure plastic comes out from the other side, we collect the separated pure copper and plastic at last!

Working process of copper wire/cable granulating machine:

1.Crushing process
Put waste copper wire into crusher to grind the wire into granulator.

2.Conveying and dust-collecting

After crushing, the mixture of copper and plastic will be conveyed to the separator, during whichprocedure the plastic granule(including fiber, rope, or dust, etc.) are cleaned by the dust cleaner

3.Separating and collecting process

The vibrating separator consists of separating board, amplitude adjustable device, and speed adjustable motor,etc.

Application of copper wire/cable granulating machine:
1.Communication wire, telephone wire, copper wire, copper wire,electric wire,computer wire, Automobile/car wire etc.
2.Single core, Double core, Multi-core etc.
3.twisted or tangled.

Features of copper wire/cable granulating machine:

1. Eco-friendly.

The whole process adopts mechanical power without water or gas, no dust, no pollution.
2. Incredible recycling rate.
The test show the recycling rate is up to 99.9%, which is a guarantee of high quality and good market of copper granule processed by our machines.
3. Labor-saving.
On account of its integrated design and intelligent design, it just needs 1-2 workers to operate, greatly saving your labor cost.

 Advantage of copper wire/cable granulating machine:

 Suits wide range of Wire/cable:

 1.Computer wire, Automobile/car wire, Telephone wie, Communication wire&cable etc.

 2.Single core, Double core, Multi-core etc.

 3.We put the waste wire/cable directly in the machine! No matter twisted or tangled together!

· High efficiency: 99% recycling rate. It can recycle copper/aluminum and plastic at the same time!

· Energy saving: It consumes less energy compared with the same products!

· Environmental friendly: no air pollution! All the dust is collected.

· Easy operation: easy installation, devices are fixed on the bottom board, easy to move or transport!

Main data of copper wire/cable granulating machine:

FAQ:

1. How can I find a proper wire granulator?

That depends on what kind of raw material you have. Generally it means, this machine can process thin telephone wire, computer wire, industrial wire, automobile wire, etc. They can be single conductor, twin core or multi core, two strand or multi strand, straight or twisted. The minimum diameter should be 0.2mm, maximum diameter is 40mm.

2. What if I have very thick wires?

You can use our wire strippers or use the two machine together.

3. Is it complicated to install or operate the machine?

Before shipping out, main parts are assembled together except for several parts for easy transportation. If raw materials are finalized, machines can also be adjusted to work well. They are PLC controlled. English manual are send out together with the machine.

About our factory:

Through 30 years of development and technology innovation, our Zhengzhou Bless Machinery Equipment Co., Ltd. has been developped to a professional manufacturer set design, manufacture, after-sale service,as a whole. In order to meet the different requirements of our customers, we designed and researched many types of  environmental equipments,including copper wire recycling machine,PCB recycling machine, Aluminum plastic recycling machine,etc.

Besides, we have also got the CE, ISO, SGS, etc, several patents, and for many years, our machines have been sold home and abroad, and are highly praised by our customers, especially the foreign customers such as Indonesia, Saudi Arabia, Malaysia, India, South Africa, Canada, Australia, Russia, Spain, Greece, Pakistan, Turkey, Egypt, Sudan, Uzbekistan, Philippines, and other countries.

Why are you choose us as your partner:

♥.1 provide the guarantee.

♥.2 we can provide the best packing as our clients requirement .

♥.3 The quality have the best ensure , and the percent pass rate is 100%.

♥.4 There are kinds of transportations : sea transportation , air transportation , expressage etc.

♥.5 Factory production, the factory price, the spot goods supply.

Our Sweet Service:

 ♥. Pre-sale service: design and manufacture machines for you as your special requirements, provide you with project, process design, and purchase programm.

♥. On-sale service: accompany with you to look around our factory, explain the manufacture process of our machines, and check the working performance of our machines.

♥. After-sale service: engineers are available to install and debugging equipments of the whole production line, besides, commissioning and training operators on site.
